Coffee & tea

What this category asks of the film

All three levels sit high, each for its own reason. Oxygen dulls the roast within days. Damp gets into ground coffee fastest, and a damp grind brews thin. Light turns the oils on a dark roast rancid, through any clear window.

Holds air out

High

Oxygen is what turns oil rancid and takes the colour and the potency out of a product. It is the slowest of the three and the one that decides a shelf life in months rather than weeks.

Holds damp out

High

Damp is the fastest of the three to show. Water between the layers delaminates the film, and in Thai humidity a weak film can lose a product in a single wet season.

Holds light out

High

Light bleaches pigment and breaks down vitamins, and a clear window lets it through as readily as an open doorway does. It is also the only barrier a buyer can see is missing.

Takes heat

xxxWe have not rated this one yet

A retort pouch is cooked with the food inside it, under pressure, above boiling point. A film that survives filling does not automatically survive the retort.

Takes a knock

xxxWe have not rated this one yet

Dry pet food and coffee beans have corners. So does a pallet on a lorry. Most failures in transit are one hole, not a whole seam.

Seals shut

xxxWe have not rated this one yet

Every barrier above this one is undone by a seal that opens. It is also the layer that has to close cleanly through spilled powder and oil on a filling line running at speed.

Prints true

xxxWe have not rated this one yet

The shelf is the only place most products meet a buyer. Gravure prints from an engraved copper cylinder, which is why the same brown holds across a run instead of drifting.

Goes back

xxxWe have not rated this one yet

A laminate of three different plastics cannot be recycled as any one of them. A mono-material structure can, and every year it reaches the same shelf life on more of the jobs.

One thing the barrier cannot do is let gas out. That is the valve's job: a one-way vent that releases the CO₂ a fresh roast gives off, without letting air back in. Skip it and the bag balloons; skip the barrier and the coffee is flat before it is sold.

Shapes that suit it

Of every shape we convert, what this category reaches for.

• Stand-Up Pouch→ซองก้นตั้ง · ซิปล็อคgram fill range50 g – 2 kgThe retail bag: zip, valve, stands on a shelf.
• Flat Bottom Pouch→ซองก้นแบน · ก้นกล่องgram fill range250 g – 5 kgFour printable faces and a flat base — the shape specialty roasters ask for by name.
• Side Gusset Pouch→ซองขยายข้างgram fill range250 g – 15 kgThe wholesale bag, cheapest per kilo of coffee.
• 4-Side Seal Sachet→ซองซีล 4 ด้านgram fill rangexxx gSingle serve, drip bags and tea.
• Roll Stock→ฟิล์มม้วนmm web widthxxx mmFilm on a reel for your own filling line.

A one-way valve can be fitted to the first three.

Structures a quote would start from

Four laminates meet the levels above.

• PET / NY / AL / RCPP

  • PETOuter face — takes the print and the knocks
  • NYToughness — takes the puncture and the drop, not the barrier
  • ALBarrier — real aluminium foil, the highest barrier there is
  • RCPPSealant — holds its seal at retort temperature
  Retort

  Retort grade, rarely a coffee structure.

  Our plant can build this.

  See this category on the formula sheet

• PET / VMPET / PE

  • PETOuter face — takes the print and the knocks
  • VMPETBarrier — aluminium vapour-deposited on film, blocks light like foil for less
  • PESealant — melts to itself to close the pouch

  The standard coffee bag. Metallised film blocks light like foil, for less.

  Industry standard — not yet confirmed on our line.

  See this category on the formula sheet

• PET / AL / PE

  • PETOuter face — takes the print and the knocks
  • ALBarrier — real aluminium foil, the highest barrier there is
  • PESealant — melts to itself to close the pouch

  Real foil, the highest barrier there is. For long export legs and single origins you want to hold a year.

  Not yet confirmed.

  See this category on the formula sheet

• PET / VMPET / NY / PE

  • PETOuter face — takes the print and the knocks
  • VMPETBarrier — aluminium vapour-deposited on film, blocks light like foil for less
  • NYToughness — takes the puncture and the drop, not the barrier
  • PESealant — melts to itself to close the pouch

  Nylon added for whole bean, which has corners, and for bags of xxx kg and up.

  Not yet confirmed.

  See this category on the formula sheet

The four figures asked first

Where production has signed a number off, it is printed. Where it has not, the box stays empty — a blank is more use to you than a guess.

Minimum order

xxxmetres of film (xxx bags)

Lead time, first run

20 – 45days from the layout you signed at Step 3

Colours in one pass

xxx

Size and seal tolerance

xxxmm

Can it keep moisture out, keep light out, hold a vacuum, take a retort?

Tell us what the pack has to survive and the film spec is built for it. That covers vacuum, and retort for a pouch that has to take pressure and heat and come out of a boiling or steaming cycle intact.

Can you run food and cosmetics work, and can you certify it?

Yes, for every industry — the line runs food-grade film from end to end. A certificate of analysis (COA) goes out with every production lot and every delivery.

What are you certified to?

ISO 9001:2015, GHPs, HACCP and BRC/IoP, all certified by BSI.

Ask for a price
